Spex•Lite® Low Cost Lightweight Fillers
SpexLite Low Cost Ultra Light Fillers & Resin Extenders
Spex•Lite® provides the world's most complete line of ultra lightweight fillers and low cost resin extenders. With a broad assortment of densities, sizes, heat and chemical resistance, Spex•Lite® can help you save material cost and weight!
NEW!
Check Back Often For New Products!
Spex•Lite® continues to develop new, low cost and high performance extenders, additives and fillers to meet the needs of customers around the globe. Check back often for new product updates, and contact us to discuss your specific requirements!
Spex•Lite® Fillers - Select Products
Here are some of the most commonly purchased Spex•Lite® products for their class or product series. Contact us to see which product would work best for you, or which size, density or performance variations you need!
Spex•Lite® Ultra Light Filler Bead Summary
Expanded Polystyrene (EPS) Products
Spex•Lite® 6503
• Typical Bead Size: ~3.2 mm
• Avg Bulk Density: ~0.75 pcf
• Softening Temp: ~ 93°C/200°F
• FR Modified
Spex•Lite® 6724
• Typical Bead Size: ~1.7 mm
• Avg Bulk Density: ~1.2 pcf
• Softening Temp: ~ 93°C/200°F
•FR Modified
Spex•Lite® 6807
•Typical Bead Size: ~1 mm
•Avg Bulk Density: ~2.2 pcf
•Softening Temp: ~ 93°C/200°F
Expanded Polyolefin (EPP) Products
Softening Temperature: ~ 148°C / 300°F
Spex•Lite® 5125
• Typical Bead Size: ~2.5 mm
• Avg Bulk Density: ~10 pcf
Spex•Lite® 5510
• Typical Bead Size: ~4.0 mm
• Avg Bulk Density: ~0.9 pcf
Spex•Lite® 5522*
• Typical Bead Size: ~2.3 mm
• Avg Bulk Density: ~2.2 pcf
• FR Modified
Spex•Lite® 5524
• Typical Bead Size: ~3.5 mm
• Avg Bulk Density: ~1.0 pcf
Ground Calcined Alumina
Melting Point : 2,072°C / 3,761.6°F
Spex•Lite® HP 2555
- d50: 5.5 microns
- Topsize: 45 microns
- Melting Point: 2,072°C / 3,761.6°F
- Smaller Sizes Available!
Bubble Alumina
Melting Point : 2,072°C / 3,761.6°F
Spex•Lite® BA 2146
- Typically ~0.8 - 2 mm
- Avg Bulk Density: ~46 pcf
- Melting Point: 2,072°C / 3,761.6°F
- Various Sizes Available!
Expanded PVDC Micro balloon
FR Coated
Spex•Lite® MB 1755
- Typically ~145 - 165 microns
- Avg Bulk Density: ~1.6 pcf
- Softening Temp: ~163°C / 325°F (time dependent)
Spex•Lite® MB 4155
- Typically ~45 - 65 microns
- Avg Bulk Density: ~2.8 pcf
- Softening Temp: ~120°C / 250°F (time dependent)
Spex•Lite® MB 1085
2
- Typically ~70 - 100 microns
- Avg Bulk Density: ~1.1 pcf
- Softening Temp: ~175°C / 350°F (time dependent)
- ATH FR Coating Applied
Average bulk density and typical bead size may vary; values provided indicate normal averages. PCF refers to pounds per cubic foot. The above information is from sources considered reliable. No warranty is expressed or implied and suitability for use in a particular application is the sole responsibility of the user.
